| Brand Name: | Huihua |
|---|---|
| Minimum Order Quantity: | 1kg |
| Price: | Negotiable |
| Delivery Time: | no limit |
| Payment Terms: | T/T |
| Supply Ability: | 100t/year |
| Material: | Nickel | Application: | Battery |
|---|---|---|---|
| Material2: | Aluminum | Advantage: | Conductivity |
| Advantage2: | Weldability | Advantage3: | Conversion Welding |
| Length: | As Your Requirements | Bonding Strength Of Nickel And Aluminum: | ≥4Kgf |
| Highlight: | thin aluminum strips,copper clad aluminum |
||
Aluminum strip has good conductivity for large capacity battery
A clad material combines two or more metal strips by bonding them together. By bonding different combinations of metals, the advantages of the individual metals are combined into a composite that is tailored to your specific product needs and requirements.
When applying clad materials into batteries, high conductivity is one of the most significant advantages. Besides, these clad materials make welding easier, and are also useful for increasing the battery's performance (higher volume and smaller size) and improving productivity as well.
Al-Ni clad materials have good conductivity and processability. They can be directly welded to lithium-ion battery aluminum casings and terminals.
| Parameter table | |
| Product name | Aluminum metal strip / aluminum nickel composite strip |
| Material purity | Nine99.98% / Al-99.6% |
| Product specification | Thickness 0.05-0.4 tolerance ± 0.015, width 1.5-100 tolerance ± 0.10 |
| Supply status | MY2Y |
| Supply shape | Rolled, flaky and shaped stamping parts |
| 180 degree bending | M ≥ 7 times, Y2 ≥ 4 times, y ≥ 2 times |
| Bonding strength of nickel and aluminum | ≥4Kgf |
| purpose | For bottom connection of aluminum shell of lithium battery, anode conversion of polymer battery, special welding of solar cell, etc |
| Components of clad materials | Thickness ratio | Specification | Product Status |
| Al/Ni | Al : Ni 1 : 2 |
depend on customers' requirements | depend on customers' requirements |
Al-Ni clad materials are often welded to the aluminum casings and terminals, in order to make welding convenient.
Packaging Details,Export standard, wooden pallet or as your requirements
Lead Time :
Quantity(Kilograms) 1 - 3000 3001 - 10000 >10000
Est. Time(days) 7 10 To be negotiated
Q: Are you trading or manufacturer ?
A: We are company,and we have our own factory
Q: How long is your delivery time?
A: Generally it is 2-3 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
Why choose us?
1. Company Profile:
The company was founded in 2004, with more than 16 years of professional experience, factory strength.
2. Production process:
The production conditions of products are closely related to the final quality of products. The equipment used in each production link is the best in the industry.
