| Brand Name: | Huihua |
|---|---|
| Minimum Order Quantity: | 1kg |
| Price: | Negotiable |
| Delivery Time: | no limit |
| Payment Terms: | T/T |
| Supply Ability: | 100t/year |
| Material: | Pure Nickel | Application: | Battery |
|---|---|---|---|
| Usage: | Tab | Advantage: | Weldability |
| Nickel Content: | 》99.6% | Color: | Nickel White |
| Density: | 8.9g/cm3 | Elongation: | ≥20% |
| Grain Size: | ≤3 | Hardness: | ≤HV200 |
| Length: | Customized | Melting Point: | 1453℃ |
| Purity: | 99.9% | Shape: | Strip |
| Surface: | Smooth | Tensile Strength: | ≥520MPa |
| Thickness: | 0.05-2mm | Tolerance: | ±0.01mm |
| Width: | 0.2-20mm | Yield Strength: | ≥240MPa |
| Highlight: | Vacuum Components Pure Nickel Sheet 2mm,Customized Pure Nickel Strip,Magnetic Pure Nickel Strip |
||
Product Description
Nickel is one of the chemical elements, the chemical symbol is Ni, the English word is Nickel, the atomic number is 28, the density is 8.9 g/cm3, the melting point is 1455°C, and the boiling point is 2730°C. It is magnetic and belongs to a transition metal.
The conductor nickel strip material refers to the material used to connect the positive and negative electrodes of the battery cells to the battery protection board.
Pure nickel strip products conform to GB/T72072-93 standard, and the purity of nickel strip is between 99.7% and 99.95%. The whole production process is vacuum smelting, impurity removal, hot rolling, cold rolling, finishing rolling, slitting and annealing, etc. More than 20 manufacturing processes. Nickel strips are mainly used for nickel-metal hydride, nickel-cadmium, lithium battery internal tab connecting pieces and battery pack connecting pieces; pins of PTC overcurrent protection components; some electric vacuum components such as sodium lamps, and some outer skins of flux-cored solder, which are specifically distributed in Electronics, electroplating, alkali production, chemical equipment, lithium batteries, battery tabs, metal stamping parts, electric vehicles, nickel batteries, telecommunications, electric vacuum, special light bulbs and other industries.
Characteristic
1. Pure nickel material has good corrosion resistance in NaOH solution of any concentration and temperature and molten NaOH above 400°C. Pure nickel material has good corrosion resistance to Na2O2, Na2CO3, NaHCO3 and alkaline solution or molten liquid containing KNO3.
2. Pure nickel is a silver-white metal with a density of 8.9g/cm3 and a melting point of 1453°C. It has excellent corrosion resistance because the surface is oxidized to form a dense and strong protective film at room temperature; pure nickel has excellent welding performance and processing performance, and can be processed into products such as pipes, rods, strips
| Parameter table | |
|
Type |
Nickel Strip |
| Grade | Pure Nickel |
| Ni (Min) | 99.9% |
| Color | nickel white |
| Application | 18650 battery pack |
Function: This product is mainly used to manufacture nickel cadmium battery, battery ear, nickel hydrogen battery, power battery, lithium battery, assembly battery, hardware stamping parts, electric tools and special lamp industry. All soft nickel aluminum strip for over welding.
1. It has good luster, ductility and weldability
2. Pure nickel strip: the content of nickel is more than 99.6%. Pure nickel has excellent mechanical properties and high corrosion resistance in many different environments. It also has the characteristics of magnetostriction and magnetism, high heat transfer, high conductivity, low gas volume and low vapor pressure.
3. The difference between pure nickel 201 and pure nickel 200 is that the highest carbon content of the former is 0.02%, and that of the latter is 0.15%;
4. Pure nickel 201 has good corrosion resistance under high temperature and high concentration of alkali and chloride ion.
5. High power tool battery pack, notebook battery and aircraft model battery combination with pure nickel tape
6. It has good spot welding performance, high tensile tension, convenient operation and low resistivity (preferred for notebook battery pack combination)
7. It can pass a current of more than 50A. It is the first choice for the combination of power batteries. This product is mainly used in the manufacturing of NiMH batteries, lithium batteries, combination batteries and electric tools, communication information, special lights and other industries.
Packing Details : Carton and wooden box packaging
Delivery Details : 2-5 days
Q: Are you trading or manufacturer ?
A: We are company,and we have our own factory
Q: How long is your delivery time?
A: Generally it is 2-3 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
